Water Electrolysis
BRE supplies High pressure Bipolar Alkaline type water electrolysis Hydrogen plants. Unlike Unipolar technology (Knowle’s cells), our electrolyzers directly produce Hydrogen at high pressure and no compressors are required. There is also no requirement of intermediate gas holders thereby making our installation very compact. There are no toxic fumes since the electrolyzer cell used in our technology is of closed cell design. Our equipment caters to requirements across many industries including Thermal power stations, oil processing, chemical processes, float glass furnaces, cylinder filling and for heat treatment requirements.
Generator
Besides DM Water, power is the single main utility requirement and it is paramount that power consumption be kept to a bare minimum. Hence, in our design power consumption only 4.8 KW per M3 of Hydrogen. At this low power consumption, our design is one of the most efficient generator in the market.
Water Electrolysis
In our design, there is no Air pollution and no fumes. Electrolyte is in closed cells so there are no fumes in the atmosphere. This also prevents blow off gases and there is no spillage of electrolyte. Safe operation is incorporated in our systems right at the design stage. Our totally automated machine allows for a safe shutdown of the entire plant in the unlikely case that there is any malfunction or loss of purity.
Plant
Transformer and Recti?er provide input power as per electrolyzer requirement. In big size hydrogen plants input power to transformer is at 3.3 KV or 6.6 KV or 11 KV. While in sizes up to 25 NM3/hr, 400 Volts LT power supply is used. BRE Bi-Polar electrolyzer is where high purity DM water is broken to h4 and O2. Hydrogen is evolved on cathode side of cells and Oxygen on anodes of cells. This design makes Electrolyzer unit very compact in size.
